| Specification |
|
|
| General Features |
|
|
|
Screen Size: |
85“ |
|
Brightness (cd/m²): |
440 |
|
Contrast Ratio: |
6000:1 |
|
Dynamic Contrast Ratio: |
300,000:1 |
|
Response Time (ms): |
15.9 |
|
Display resolution (H x V, pixels): |
3840 x 2160 |
|
HDR (High Dynamic Range) compatibility: |
Yes (HDR10,HLG,Dolby Vision) |
|
Aspect Ratio: |
16:9 |
|
Portrait/Tilt Compatibility: |
Yes |
| Display Features |
|
|
|
Dimming type: |
Frame Dimming |
|
Display Device: |
LCD |
|
Panel Type: |
VA |
|
Backlight type: |
Direct LED |
|
TRILUMINOS Display: |
TRILUMINOS PRO |
|
Color gamut (DCI-P3): |
92% |
|
Picture Processor: |
4K HDR Processor X1 |
|
Operation time: |
24/7 |
|
Deep Black Non-Glare coating: |
No |
|
Haze (%): |
2% |
|
Viewing Angle (Right/Left): |
178(89/89) degree |
|
Viewing Angle (Up/Down): |
178(89/89) degree |
| Video Specs |
|
|
|
Video Processing: |
4K X-Reality PRO |
|
Motion enhancer: |
Motionflow XR 240 (Native 60Hz) |
|
HDMI Signal: |
4096x2160p (24,60Hz)3840x2160p (24,30,60Hz)1080p (24,30,60Hz)1080i (60Hz)720p (24,30,60Hz)480p |
| Audio Specs |
|
|
|
Speaker Position: |
Down Firing |
|
Audio Power Output: |
10W + 10W |
| Professional Features |
|
|
|
Pro mode: |
Yes |
|
HDMI auto wake-up: |
Yes |
|
HTML5 platform: |
Yes |
|
Multicast/IPTV: |
Yes |
|
Operating System: |
Android TV |
|
On-board Storage (GB): |
16GB |
|
| Network Specs |
|
|
|
Wi-Fi Direct: |
Yes |
|
Wi-Fi Certified: |
Yes |
|
Wireless LAN: |
Integrated |
| Convenience Features |
|
|
|
USB playback codecs: |
MPEG1:MPEG1 / MPEG2PS:MPEG2 / MPEG2TS (HDV,AVCHD):MPEG2,AVC / MP4 (XAVCS):AVC,MPEG4,HEVC / AVI:Xvid,MotionJpeg / ASF (WMV):VC1 / MOV:AVC,MPEG4,MotionJpeg / MKV:Xvid,AVC,MPEG4,VP8.HEVC / WEBM:VP8 / 3GPP:MPEG4,AVC / MP3 / ASF (WMA) / LPCM / WAV / MP4AAC / FLAC / JPEG |
|
On Screen Clock: |
Yes |
|
Sleep Timer: |
Yes |
|
On/Off Timer: |
Yes |
|
Chromecast built-in: |
Yes |
|
Apple AirPlay: |
Yes |
|
IP Control: |
Yes |
|
RS-232C Control: |
Yes |
| Control Specs |
|
|
|
IP Control: |
Yes |
|
RS-232C Control: |
Yes |
|
HDMI-CEC: |
Yes |
| Inputs and Outputs |
|
|
|
HDCP: |
HDCP2.3(for HDMI1/2/3/4) |
|
Composite Video Input (s): |
1(Side, Mini jack) |
|
HDMI inputs total: |
4(4Side) |
|
Analog Audio Input (s) (Total): |
1(Side Analog Conversion) |
|
Digital Audio Output (s): |
1(Side) |
|
USB ports: |
2(Side) |
|
Ethernet inputs: |
1(Side) |
| Design Features |
|
|
|
VESA® Hole Pitch (W x H): |
400 x 400 mm / 15 3/4 x 15 3/4 inch |
| Accessories |
|
|
|
Wall-mount adjuster (Bundled)*depending on the region: |
Yes |
|
Table-top stand (Optional)*depending on the region: |
Yes |
| Environment Specs |
|
|
|
Rated Power Consumption: |
248 W |
|
Power Consumption (in Standby): |
0.5 W |
|
Dynamic Backlight Control: |
Yes |
|
Power Saving Mode / Back Light Off Mode: |
Yes |
| Measurements |
|
|
|
Dimension of TV without Stand (W x H x D): |
1899 x 1089 x 71 mm / 74 7/8 x 42 7/8 x 2 7/8 inch |
|
Dimension of TV with Stand (W x H x D): |
- |
|
Dimension of Package Carton (W x H x D): |
2036 x 1239 x 258 mm / 80 1/4 x 48 7/8 x 10 1/4 inch |
| Weight |
|
|
|
Weight of TV without Stand: |
44.5 kg / 98.1 lb |
|
Weight of TV with Stand: |
- |
|
Weight of Package Carton (Gross): |
62 kg / 136.6lb |
| Further Information |
|
|
|
Product Information Sheet (Europe Only): |
Product Information Sheet |
| Warranty Info |
|
|
|
Manufacturer's Warranty*: |
3 Years on site, advanced replacement by a new or refurbished unit in case of product fault. Logistics included. |
|
| Faulty From New*:
(Within 28 Days Of Purchase) |
Return to AWE for assessment.
Please complete this online Returns Form |
|
| After 28 Days Of Purchase*:
(Within The Manufacturer's Warranty) |
The repair is managed by Sony.
Please contact Sony Professional Prime Support:Via email Via 02039015561 (option 2) |
|
| *Terms & Conditions: |
For further information regarding AWE's returns procedures please see chapters 7 & 8 in our Terms & Conditions |
