HDA MHUB411U40 MHUB 4x1+1

Additional Information

Description Specification Downloads

HDA MHUB411U40 MHUB (4x1+1) 4K 40m A small but mighty MHUB for all homes.

Designed for small homes and apartments the MHUB U (4x1+1) is the newest addition to the affordable MHUB U range. WiFi enabled and with x2 additional IR ports, CEC control and 18G 4K HDMI interfaces with up to 40m transmission range, this MHUB represents all of our innovation wrapped up in this little box.

Cloud monitorable 4x1+1 HDMI/HDBT+HDMI matrix system with a 40m UHD 4K or 70m 1080p transmission range. An integrated IP>IR control processor enables property-wide control of all the connected sources and displays via the free uControl universal remote App or Alexa voice commands. Multichannel audio or stereo extraction can be selected to match any of the display zone outputs A or B.

Form factor: Compact unit. Mountable with optional mounting wings
Inputs x outputs 4 HDMI x 1 RJ45 HDBaseT + 1 HDMI + 1 mirrored HDMI
Transmission tech.: HDBaseT (VS010) + TPC and HDMI
Video bandwidth: HDMI backplane 594MHz clock / 18Gbps data HDBT 340MHz clock / 10.2Gbps data
ESD protection: ± 8kV (air-gap discharge) ± 4kV (contact discharge)
Hub control Web GUI, IR, TCP/IP, RS232, App, Alexa
App control: Full control over sources, matrix hub & display functions.
Control : App Control, Voice Control, IP, RS232 & IR
Dimensions (H x W x D): Hub 220 / 200 / 45mm (without feet)
RX 140 / 65 / 17mm
Manufactures Warranty*: 2 Years, 5 Years by Cloud Registration (Cloud Registration must be completed within 30 days of installation for the extended warranty period to be activated).
Faulty From New*:
(Within 28 Days Of Purchase)		 Return to AWE for assessment.
Please complete this online Returns Form
After 28 Days Of Purchase*: Return to AWE for assessment.
Please complete this online Returns Form
*Terms & Conditions: For further information regarding AWE's returns procedures please see chapters 7 & 8 in our Terms & Conditions

Features

  • Supports source content up to and inc. Ultra HD 4K 60 4:4:4 with High Dynamic Range (HDR) formats inc. Dolby Vision®
  • Display receiver powered via PoH
  • IR over HDMI injector dongle included
  • Web GUI for easy config and setup (MHUB-OS)
  • Remote system monitoring (HDA Cloud)
